AquaROBO-ROLL is a robotic fountain nozzle that moves on three axes: ±90° on the X-axis, +90°/−70° on the Y-axis and a full, unlimited 360° rotation on the third axis. Three servo motors drive the movement, and an integrated IMU sensor calibrates the unit automatically. It runs on 24 VDC under DMX-RDM control with a single IP68 cable connection, and a Syncronorm Depence library is available for show programming. Fan and finger nozzles fit on its flange connection, and two AquaLIGHT units can be added to light the jet.
X-axis 180°, to +/-90° from Zero Position Y-axis 180°, to +90°/ -70° from Zero Position Z-axis 360°, limitless
Why choose
AquaROBO - ROLL
Robust Stainless Steel Body
24VDC Powered & DMX-RDM Controlled
IP68 Socket One Cable Connection
Syncronorm Depence Library available
Different Nozzle Types With Flange Connection
IMU Sensor Integrated for Auto Calibration
AquaLIGHT x2 (Optional)
Park Position and Zero Position Commands
Servo Drive Control on 3-axis
Moving Axis;
X-axis 180°, to +/-90° from Zero Position Y-axis 180°, to +90°/ -70° from Zero Position Z-axis 360°, limitless
